Product by Royal Service Air-Conditioning
NAME: Smart Variable Air Diffusers
MODEL: RS SVAD SERIES
PRODUCT CODE: RS- SVAD-ST
Smart VAD • Wide Applications
RS Variable Air Diffusers are ceiling diffusers with built in damper motors / actuators for varying the air volume. The dampers are continuously adjusted by damper motors/actuators which controlled y thermostat. Remote control as optional.
RSV-SVAD building application that can be designed engineered, such as closed or open offices, libraries, meeting rooms, exhibition halls, shopping markets, rest rooms, banquet halls etc.
RS Variable Air Diffusers are suitable for all kinds of air conditioning engineering construction, such as HOTEL, villa, APARTMENT, OFFICE BUILDING, HOSPITAL, school, mall, Sports venues, Leisure Facilities, supermarket, WAREHOUSE, WORKSHOP, Park, farmhouse, Courtyard etc.
New building construction development benefits:
Provide individual zones with class one temperature control with a lower initial investment.
Upgrading projects:
Upgrade the original air conditioning system without any air duct-work changes, realize individual zone temperature control to a over cooled or heated zone.
Meet specific requirements:
Meet the special temperature control requirement of an air conditioning zone easy and a affordable way. Improve the unsatisfied, uncomfortable, energy wasting areas in an air conditioning system that is existing.
| PRODUCT INFORMATION & FEATURES |
| MODEL | SVAD Series-smart vairable air diffusers |
| TYPE | VAV terminal units box |
| APPLICATION | Individual Zone Temperature Control, Varying Air Volume |
| FEATURES | ♦ Superior air distribution ♦ Easily adapts to office changes ♦ Lower cost per zone ♦ Reliable and durable quality ♦ Easy maintenance ♦ Automation control capabilities |
| HOUSING/CASING | Galvanized Steel |
| INLET SIZE | 6'' 8'' 10'' 12'' INCHES |
| SHAPE OPTION | Round, Square, Linear, Swirl |
| WARRANTY | 1 Years |
| CONTROL OPTION | Local Control. (Stand-alone) Wired wall thermostat or Remote control;
RSCWEB-Control: Web control allows you to see the control of the diffusers |
| KEY WORDS | Air handling unit, Air Valve, Air Damper, Air Regulator, Volume Control, Air Distribution,
Air Diffuser, Air Terminal Units Box, VAV, VAD, SVAD |
| OEM & ODM SERVICE | ACCEPTABLE, please send us your requirements |
RS Electric Variable Air Diffuser are equipped with a control board, an actuator (stepper motor), a thermostat or a remote controller (Optional). The control board compares setting temperature with room temperature, uses the PID to adjust the damper position to keep the room temperature constantly at the set point. When the HVAC load changes, the control board will correct the damper position to adapt to the HVAC load changes every three minutes.
RS Variable Air Diffusers can be used in several air conditioning engineering applications, such as offices, libraries, meeting rooms, exhibition halls, markets, rest rooms, banquet halls etc.
Surface Finish: Powder coated color finish as per RAL color
Standard color: Standard White RAL9016, RAL9010
Size Option:
Standard 595 X 595 mm
Clip Ceiling 600 X 600 mm
US Standard 603 X 603 mm
Small Type 320 X 320 mm
Custom size A X A mm
Smart Electric Square VAV Diffuser
Smart Electric Square VAV Diffuser – Square Plaque with four perimeter dampers providing variable discharge area at the perimeter of the diffuser for maximum Coanda effect and to avoid dumping.
