RSV-SVAD-WL Wall-Mounted Linear Smart VAV Diffuser

规格

Features of RSV Smart Variable Air Diffuser

Individual Comfort control
Each engineered RSV Smart Variable Air Diffuser has an adjustable, local sensors for remote or wall mounted thermostat, creating individual zones of comfort. It can not only control the temperature of different rooms, but also can maintain and control the temperature in different areas of the same open space.
Standard room settings 21 C-26 C/70F-785F Optional 22C-27C/715F- 80F.

Uncomplicated installations deployment to office layout changes
Systems designed with RSV SVAD have advantages over designed systems with VAV terminals because VADS are more adaptable to office layout changes. No single smart VAD zone is split up when new office walls are put up or moved, a common problem with VAV systems. If it is necessary to move a thermal VAD, it’s plug and play are simple to extend low voltage control and easier for remote controlled units. RSV SVAD is in comfort control at all times.

Low energy VAV terminal
Compare with VAV terminals, the smart SVAD systems greatly reduce the total air pressure drop compared to VAV terminals allowing a low pressure designed air duct-work system, less fan motor energy with low energy operation; fan energy is further reduced when the air handlers operate with variable speed drives. Each RSV SVAD offers comfortable individual zone control, no portion of the building zone is overcooled or overheated, thus superior low energy consuming system. Additional benefit, each RSV SVAD is a controlling VAV terminal and the control is stand alone or connect to a BA system. SVAD operate and turn down to work at low static duct pressure of(10 pa/0.04in w.g.)

Class 1 building air distribution
Your system design is your signature, standard fixed opening diffusers designed in a VAV terminal system discharge outlets are fixed allowing the air velocity to be variable. ariable as a terminal lowers the supply flow. This condition is uncomfortable as low air velocity dumps minimum air into the zone, resulting in cold unmixed air supply. RSV SVAD vary the discharge opening varying air volume, thus maintaining a constant discharge air velocity, increasing better throw, steady comfortable air movement and uniform temperature mixing distribution within the air conditioned space.

Constant mixing operation
Each diffuser is designed to mix air into room and sense the rooms air temperature. In the diffuser a venturi nozzle is designed to use primary air and vent a small quantity of air at a higher velocity and in turn move air across the diffusers. Because this air is at a higher velocity the diffuser will pick up room air and mix the primary and throw the air across the diffuser and mix again into the room. Our R-models sensor senses the room temperature for control.

Cost per zone are lower
RSV SVAD installation skills are no different then installing standard diffusers. Lower cost than resetting a VAV terminal controller. In addition, RSV SVAD requires limited wires, no penumatic tubing and no medium air pressure system design that can waste energy, saving material and labor costs, and operating cost.

Precise room temperature control
RSV SVADS modes thermostat controls and actuates by adjusting the dampers to maintain a comfortable room temperature average within 1.5F/0.9 C of the temperature selected.

Low maintenance
RSV SVAD once installed requires little maintenance RSV SVAD requires standard diffuser cleaning intervals by step instructions for faults a display will show Error codes Check room temperature, change of sensor, communication. actuator and remote control.

Architecture friendly appearance
Simple and smooth line profile with RSV SVADS are a easily accepted by architects in a layout of ceilings to match different decorations. Standard color (RAL9016)or adapted a different color each appreciated by both architects and interior designers. No wall thermostat is needed

Smart VAD • Wide Applications
RS Variable Air Diffusers are ceiling diffusers with built in damper motors / actuators for varying the air volume. The dampers are continuously adjusted by damper motors/actuators which controlled y thermostat. Remote control as optional.

RSV-SVAD building application that can be designed engineered, such as closed or open offices, libraries, meeting rooms, exhibition halls, shopping markets, rest rooms, banquet halls etc.

RS Variable Air Diffusers are suitable for all kinds of air conditioning engineering construction, such as HOTEL, villa, APARTMENT, OFFICE BUILDING, HOSPITAL, school, mall, Sports venues, Leisure Facilities, supermarket, WAREHOUSE, WORKSHOP, Park, farmhouse, Courtyard etc.

New building construction development benefits:
Provide individual zones with class one temperature control with a lower initial investment.

Upgrading projects:
Upgrade the original air conditioning system without any air duct-work changes, realize individual zone temperature control to a over cooled or heated zone.

Meet specific requirements:
Meet the special temperature control requirement of an air conditioning zone easy and a affordable way. Improve the unsatisfied, uncomfortable, energy wasting areas in an air conditioning system that is existing.
